YKJ-77034NL HX1234NLT Pulse

YKJ-77034NL HX1234NLT Pulse

INGKE YKJ-77034NL 100% cross HX1234NLT Pulse

Part No.: HX1234NLT

INGKE Part No.: YKJ-77034NL

Made in China: INGKE Technology

Description: HX1234NLT Pulse Ethernet (POE) LAN Transformer

MOQ: 1PCS

Lead Time: within 1 week

Product: LAN Transformer

Termination Style: SMD/SMT

Frequency Range: 1 MHz to 125 MHz

Inductance: 350 uH

Isolation Voltage: 1.5 kV

Length: 28.58 mm

Width: 12.19 mm

Height: 7.36 mm

Application: 100 Base-T

Operating Temperature: -40℃～105℃

Product Category: Audio Transformers / Signal Transformers

Moisture Sensitivity Level (MSL): 1 (Unlimited)

RoHS Compliant and REACH

100% compatible, 100% test, warranty for 60 months

Factory with UL, supplier of Marvell & Honeywell

Chinese UL factory for producing HX1234NLT Pulse LAN Transformer
